AnsaldoSTS 95 - Wiring Diagram for Pedestrian Mechanism 12-Volt Systems

General Maintenance and Troubleshooting
2-8 SM 6495, Rev. 7, December 2008
2.3.5. Wiring Diagram for Pedestrian Mechanism 12-Volt Systems
Connect the wires to the Terminal Board as shown in Figure 2-6 and Figure 2-7 for 12-volt systems
NOTE
The wiring diagrams in Figure 2-6 and Figure 2-7 have the spare,
unused terminals on the lower terminal block. Gate mechanisms
produced prior to July 5, 2004, have wiring arrangements that had the
spare/unused terminals on the upper block.
