5.3. Model 95 Sidewalk Gate Mechanism - Mechanical Assembly Parts List
Table 5-4 and Figure 5-7 through Figure 5-9 list the parts for the Model 95 Sidewalk Gate Mechanism
mechanical assemblies.
Table 5-4 - Model 95 Sidewalk Gate Mechanism - Mechanical Assembly Parts List
Item
Number
Part Number Part Description
03* M46700101 Mechanical Gearbox (Includes Items 5 and 10)
05 M46700102 Mechanical Gearbox (Included in Item 3)
07 J47599990005 U-Bolt Assembly
10 N46700402 Cover with Hasp (Included in Item 3)
12* J4802110108 Nut, 1/4 - 20 SS Hex (Included in Item 7)
15 Q46702101 Casting, Cover Latch
20 N46710203 Cover Latch Assembly
25 J0680140006 Spring - Pin 1/4 Dia SS
30 M46707401 Groove Pin - 3/8 x 2-1/2 SS (with hole for Bridge Pin, Item
180)
31 J703394003 Groove Pin - 3/8 x 2-1/2 SS
35 M46707301
M46707302
Shaft, Mod 95 Main R.H.
Shaft, Mod 95 Main L.H.
40 N46703602 Gearmotor - 1/6 HP with Brake Assembly
45 M46700701 Gearmotor Drive
50 M46700801 Gear, Large Idler
55 M46700802 Gear, Small Idler
60 M46700901 Gear, Segment Drive
65 J7256450012 Bearing – Roller 209PP
70 J7120580006 Ring - #209 Internal Snap
75 M46700803 Shaft, Idler Gear
80 M46700804 Key, Idler Gear Shaft
85 J7256450011 Bearing – Roller 205PP
90 J7120580004 Ring - #205 External Snap
N46701401 Gear Shock Assembly
95
N46701402 Optional Severe Weather Shock
100 M46701101 Cover, Gear Shock
105 J6909510007 Gasket - Model 95 Shock
110 J0523620003 Screw, 3/8-16 x 1-1/4 Hex Socket
115 M46700805 Key, Segment Gear
120 J7120580005 Ring - #205 Internal Snap
125* J7762830001 Cam - Model 95 Circuit Cont
130 J5001010105 Screw - 1/4 - 20 x 5/8 Hex Cap SS
135 J4751210113 Washer - SS Lock, 3/8”
140 J5000970116 Screw, 1/4 –20 x 1 Hex SS
145* J041245 Threadlocker – 242
150 J6909510008 Gasket – Silicone
155 J0504980002 Set Screw 1/4 – 20 x 5/16
160 J0504980003 Set Screw 1/2 - 13 x 1/2
165 J048417 Nut, 1-1/2 Cndt Lock
180 J0487220007 Pin - Bridge - 3/8”
185 J0680140008 Spring - Pin 1/4 Dia SS
195 J4751200112 Washer, SS Plate No 1/4
