AnsaldoSTS 95 - 5.1. Mechanical Assembly Parts Lists

Parts List
5-2 SM 6495, Rev. 7, December 2008
5.1. Model 95 Gate Mechanism – Mechanical Assembly Parts List
(12- and 24-Volt Systems)
Table 5-2, Figure 5-1, and Figure 5-2 list the parts for the 12- and 24-volt Model 95 Gate Mechanism
mechanical assemblies.
Table 5-2 - Model 95 Gate Mechanism – Mechanical Assembly Parts List for
12- and 24-Volt Systems
Item
Number
Part Number Part Description
05 M46700101 Mechanical Gearbox
07 J47599990005 U-Bolt Assembly, 1/4” – 20 Hasp
10 N46700401 Cover with Hasp
12 J4802110108 Nut, 1/4” – 20, SS Hex (Included in Item 7)
15 Q46702101 Casting, Cover Latch
20 M46710202 Threaded Rod, 3/8” – 24 x 4”
21 M46710201 Cover Latch Hook
25* J0680140006 Spring – Pin ¼ Dia SS
30 M46707401 Groove Pin – 3/8 x 2-1/2 SS (with hole for Bridge Pin, Item 180)
35 M46700601 Shaft, Mod 95 Main
40 N46703602
N46703604
Gearmotor – 1/6 HP (12 VDC)
Gearmotor – 1/6 HP (24 VDC)
45 M46700701 Gearmotor Drive
50 M46700801 Gear, Large Idler
55 M46700802 Gear, Small Idler
60 M46700901 Gear, Segment Drive
65 J7256450012 Bearing-Roller 209PP
70 J7120580006 Ring - #209 INT Snap
75 M46700803 Shaft, Idler Gear
80 M46700804 Key, Idler Gear Shaft
85 J7256450011 Bearing – Roller 205PP
90 J7120580004 Ring - #205 External Snap
N46701401 Gear Shock Assembly
95
N46701402 Optional Severe Weather Shock
100 M46701101 Cover, Gear Shock
105 J6909510007 Gasket - Model 95 Shock
110 J0523620003 Screw, 3/8-16 x 1-1/4 Hex Socket
115 M46700805 Key, Segment Gear
120 J7120580005 Ring - #205 Internal Snap
125 J7762830001 Cam – Model 95 Circuit Cont
130 J5001010105 Screw - 1/4 - 20 x 5/8 Hex Cap SS
135 J4751210113 Washer – SS Lock 3/8”
140 J5000970116 Screw, 1/4 –20 x 1 Hex SS
145* J041245 Threadlocker – 242
150 J6909510008 Gasket – EPMD Sponge, Black
155 J0504980002 Set Screw 1/4 - 20 x 5/16
157 J4750780002 Washer - 15/16 ID 3” OD
160 J0504980003 Set Screw 1/2 - 13 x 1/2
162 J0480750004 Nut - 7/8” - 9 Lock
165 J048417 Nut, 1-1/2 Cndt Lock
180 J0487220007 Pin – Bridge - 3/8”
185 J0680140008 Spring – Pin 1/4” Diameter, SS
