Parts List

5-34 SM 6495, Rev. 7, December 2008

5.11. Recommended Model 95 Non-Vital Gate Mech Spare Parts Kit (X46700016)

Table 5-12 lists the parts in the Model 95 Spare Parts Kit (N46700016).

Table 5-12 - Parts List for Spare Parts Kit (N46700016)

Part Number Part Description

N46703602 Gearmotor - 1/6 HP

N46716401 MCR NV Relay w/Ties and Label

N46704205 # 1 Contactor Assembly

N46704302 Heel Contact Assembly

N46704403 Front Contact Assembly

J7256940169 Circuit Breaker, 12V, 20A, Reset

X46700038 Snub Diode Assembly

X46700031 Power Down Module

N156682001 Limit Resistor

N156682 Snub Resistor

J0702050438 Electric Brake Assembly (Hold Clear Device)

5.11.1. Recommended Spare Parts Not Contained in the Spare Parts Kit

Table 5-13 lists other recommended spare parts that are not included in the spare parts kit (Table 5-12).

Table 5-13 - Other Recommended Spare Parts

Part Number Part Description

J0702050635 Replacement Motor Brushes (2 per motor required)

5.12. Model 95 Gate Mech Torque Wrench Kit (X46700003)

Table 5-14 lists the parts in the torque wrench kit (X46700003).

Table 5-14 - Torque Wrench Kit (X46700003)

Part Number Part Description

J0390000115 Torque Wrench

J0390000117 Socket, 7/16" 12 Point, 1/4" Sq Drive
