Parts List
SM 6495, Rev. 7, December 2008 5-29
5.8. Non-Vital Pedestrian Mechanism Relays Electrical Assembly for 12-Volt Systems
(N46782201, N46782202)
Table 5-9 and Figure 5-14 list the parts for the 12-volt Model 95 gate mechanism electrical assembly
with the PN-150 Relay).
Table 5-9 - Parts List for the 12-Volt Electrical Assembly for Non-Vital Pedestrian
Mechanisms
Item
Number
Part Number Part Description
05 N46708702 Relay Mounting Bracket
10 N46716401 MCR NV Relay w/Ties and Label
30 J7257150018 Terminal Board Block, Black
35 J7256940403 Circuit Breaker, 10 Amps, 12 VDC
40 N156682 Resistor
42 N156682001 Resistor
45 M107471 Terminal board
55 J5001240242 Screw, 8 - 32 x 1/2, w Lock Washer
60 J4751200109 Washer, No. 8 Plate, SS
65 J4751210108 Washer, No. 8 Lock, SS
70 J5001390114 Screw, 1/4 - 20 x 7/8, SS
75 J5001320128 Screw, 8-32 x 1-3/4, SS
80* N46704205 No. 1 Contact Assembly
85* N46704302 Heel Contact Assembly
90* N46704403 Front Contact Assembly
110* M130200 Terminal Post
112* M118271 Terminal Post
115* M4510113501 Washer, Lock
120 J047818 Washer, 17/64 x 9/16 Cop
125 J480300 Nut, 14-24 Brass, Hex Head, NP
130 J480301 Nut, 14-24 Brass, Hex Head
135* M4510113402 Washer, Insulated
140* J071626 Link, Test
145* M047290 Connector, No. 18 x 1/2
150 N46706603 Harness Assembly, Pedestrian PB
155 J047521 Washer, High Collar Lock, 1/4”
165 J4802110108 Nut, 1/4 - 20, Hex Head, SS
170 J048145 Nut, 10 - 32 Hex Head, Steel
175 O0305047 Washer, No. 10 Flat
190 J703310 Cable, Tie Self Locking
191 J5000970112 Screw, 1/4 - 20 x 3/4 Hex Head, SS (N46782201 Only)
200 X46700038 Model 95 Snub Diode Assembly
210 N46707702 Assembly, Resistor Bracket
205 J4751820013 Washer, No. 8, Flat Nylon
265 J7915970003 Screw, 8 - 32 x 3/4, Nylon RH
275 N46712401 Model 95 PCB
325 M109154 Terminal Block
330 J5000970114 Screw, 1/4 - 20 x 7/8 Hex Head, SS
335 J4751210124 Washer, lock, 1/4”, SS
340 N46717101 Relay Brake Assembly
To Next Page
