AnsaldoSTS 95 - Figure 2-3 - Wiring Diagram for 12-Volt Systems - Without Maintenance Switch

General Maintenance and Troubleshooting
2-10 SM 6495, Rev. 7, December 2008
SPARES
(MAY BE USED
FOR ARM LIGHTS)
MODEL 95 GATE MECHANISM WIRING DIAGRAM
FOR STD. UNITS WITHOUT MAINT. SWITCH
LABEL PART NO. M46705201 / US&S DWG. B467052 REV. 6
OPTIONAL HEATER
INDICATION (SEE NOTE 1) GATE DOWN XRP (SEE NOTE 2)
N12
B12 UP CONTROL
TEST LINK BETWEEN 5B & 6B OPENS WITH GOLD NUT LOOSENED.
MCR
SEE NOTE 4.
C1
A1
(B2)
C9/ A9
(F2)
C7/ A7
C8/ A8
(H2)
B11
(H3)
C11/ A11
(H4)
(F4)
(B3)
B12 C10/ A10
C12/ A12
(B4)
HC
(BRAKE)
M
OTOR
T7
T6
T5
T4
T3
T2
T1
R2
R1
SNUB
RES
SNUB
DIODE
BAT
AUX
CIRCUIT
BREAKER
POWER
DOWN
MODULE
R3
LIM
RES
R4
_
+
_
+
1A
2A
3A
4A 5A
6A
1B
2B
3B
4B
5B 6B
1C 2C
3C
4C
5C
6C
NOTE 1: ADD JUMPER 2C-5C FOR GATE DOWN IND.
NOTE 2: ADD JUMPER 2C-6C FOR POS. XRP OR 4B-6C FOR NEG. XRP. NOTE 3: DASHED WIRES INDICATE USER WIRING. NOTE 4: RELAY TERMINATIONS AS SHOWN ARE FOR PN-150HD. LETTERS IN PARENTHESIS ARE FOR NON-VITAL RELAY.
CONTACT CLOSED FUNCTION
1 FRONT
2
3 4
5
6
0 - 89 DEG 46 - 93 DEG 5 - 93 DEG
0 - 5 DEG 83 - 90 DEG
MOTOR UP VACANT SLOT
MOTOR DN
BELL
GATE DN IND
FLASHING LIGHT
UNION SWITCH & SIGNAL
645 RUSSELL ST.
BATESBURG, SC. 29006
UG0106.0028.00
Figure 2-3 - Wiring Diagram for 12-Volt Systems – without Maintenance Switch
