Parts List
SM 6495, Rev. 7, December 2008 5-37
5.16. Gate Arm Light Fuse Retrofit Kit
Table 5-18 lists the parts included in the gate arm light fuse retrofit kit (X46700039).
Table 5-19 lists the parts included in the fuse holder assembly (N46719101).
Table 5-18 - Parts List for the Gate Arm Light Fuse Retrofit Kit (X46700039)
Item
Number
Description Part Number Quantity
1 Fuse Holder Assembly N46719101 1
2 Screw, 1/4 x 20 x 7/8” J5001240181 2
3 Installation Manual S006495E 1
Table 5-19 - Parts List for the Fuse Holder Assembly (N46719101) (Figure 5-18)
Item
Number
Description Part Number Quantity
1 Mounting Bracket M46718901 1
2 Fuse Box, 4 Gang ATC No. HL62935 J7100380196 1
3 Fuse, Automotive 10A, 32V, Red J7100380131 4
4 Terminal Block M108571 1
5 Screw, 8 – 32 x 5/8 Hex Head, SS J5072950120 2
6 Nut, 8 - 32 Elastic Stop J048080 2
7 Washer, No. 8 Plate SS J4751200109 6
8 Screw, 1/4 – 20 x 7/8 Fil Head SS J5001390114 1
9 Nut, 1/4 - 20 Elastic Stop J480260 1
10 Washer, 1/4 Plate SS J4751200112 1
11 Washer, 17/64 x 9/16 Cop J047818 12
12 Nut, 14 - 24 Hex Brass NP J480300 4
13 Nut, 14 - 24 Hex Brass J480301 4
14 Wire, w 14PVC Black M258 M258-30 A0455190001 3
15
Terminal, Pre-insulated Dia.G, No.
321045
J730044 4
16
Terminal, Faston No. 16-14 No.
640905-1
J7091460520 4
17 Label, Vinyl Cloth J0759550002 8
18 Label Fuse Holder Assembly M46719001 1
