Parts List
5-20 SM 6495, Rev. 7, December 2008
5.5. Non-Vital Relay Electrical Assembly for 12-Volt Systems (N46782001)
Table 5-6 and Figure 5-11 list the parts for the 12-volt Model 95 gate mechanism electrical assembly
with non-vital relay).
Table 5-6 - Parts List for the 12-Volt Electrical Assembly with Non-Vital Relay
Item
Number
Part Number Part Description
05 N46708702 Relay Mounting Bracket
10 PN46716401 MCR NV Relay w/Ties and Label
30 J7257150018 Block - Terminal Board Black
35 J7256940169 Circuit Breaker – 12V 20A Reset
40 N156682 Resistor, Comp
42 N156682001 Resistor, Comp
45 M107471 Block, 4-Way Terminal
55 J5001320108 Screw, SS, 8 - 32 x 1/2 RD
60 J4751200109 Washer, SS Plate No 8
65 J4751210108 Washer, SS Lock No 8
70 J5001390114 Screw, SS 1/4 - 20 x 7/8
75 J5001320128 Screw, SS 8 - 32 x 1-3/4
80* N46704205 #1 Contact Assembly
85* N46704302 Heel Contact Assembly
90* N46704403 Front Contact Assembly
110* M130200 Terminal Post, AAR
112* M118271 Term Post, AAR
115* M4510113501 Lock Washer
120 J047818 Washer, 17/64 x 9/16 COP, AAR
125 J480300 Nut, 14 - 24 Hex Brass NP, AAR
130 J480301 Nut, 14 - 24 Hex Brass, AAR
135* M4510113402 Washer, Insulating
140* J071626 Link, Test
145* M047290 Connector, #18 x 1/2”
150 N46706602 Harness, PB
155 J047521 Washer, high collar lock, ¼”
165 J4802110108 Nut, ¼ - 20 SS Hex
170 J048145 Nut, 10 - 32 Hex Steel
175 00305047 Washer, #10 Flat
190 J703310 Cable, Tie Self Lkg
191 J5000970112 Screw, 1/4 - 20 x 3/4 Hex HD SS
200 X46700038 Diode Assembly, Snub Mod. 95
205 J4751820013 Washer - #8 Flat Nylon
265 J7915970003 Screw, 8-32 x 3/4 Nylon RH
270 M437500 Spacer
275 N46712401 Power Down Module
280 J507218 Screw, 1/4 – 20 x 5/8 SS
285 J4751210111 Washer, 1/4 SS Lock
290 J5001390116 Screw, SS, 1/4 – 20 x 1 FIL
300 N46705602 Diode Assembly. Limit
305 J7355190364 Resistor, 50 ohm, 5 Watt
310 J730041 Terminal, pre-insulated, diamond grip
325 M109154 Terminal Block, 3-Way
330 J5000970114 Screw, 1/4 - 20 x 7/8 Hex
335* J4751210124 Washer, 1/4 SS Lock
To Next Page
