Parts List
SM 6495, Rev. 7, December 2008 5-33
5.10. Tool Kit (N46707001)
Table 5-11 lists the parts in the tool kit (N46707001 and Figure 5-17 identifies the parts in the tool kit.
Table 5-11 - Parts List for Tool Kit (N46707001)
Item Number Part Number Part Description
05 J0390000119 Tool Bag - #166 Zip Vinyl
10 M46706901 Pin, Hold Down
15 J0390000116 Hex Key, 3/16" Ball Point (Cams)
20 J0529800014 Hex Key, 5/64" Short Series (Brake)
25 J0529800015 Hex Key, 1/8" Short Series (Pinion)
30 J0529800016 Hex Key, 9/64" Short Series (Brake)
35 J0529800017 Hex Key, 5/16" Short Series (Buffers)
40* A7737150007 Velcro, 3/4”, Hook/Loop, Black
45* M46717401 Warning Label
* Part Not shown in Figure 5-17
Figure 5-17 - Tool Kit (N46707001)
