AnsaldoSTS 95 - Parts List

To Next Page

To Previous Page

Parts List

SM 6495, Rev. 7, December 2008 5-3

Item

Number

Part Number Part Description

190 M46700806 Hub Key

195 J4751200112 Washer, SS Plate, No. 1/4

200 J4751210111 Washer, SS Lock No. 1/4

205 J056448003 Eye Bolt, 1/2” – 13, SS

210 J4803170110 Nut , 1/2” – 13, Heavy Jam, SS

220 J480217 Nut, 1/2” – 13, Elastic Stop

305 M46710204 Hold, Threaded

310 00205112 Hex Nut, 18 – 8, 3/8” - 24

315 J4751200114 Washer, SS Plate, 3/8”

320 M46703901 Cam Clamp

505 X46703702 T-Bolt Kit

510 M46705201

M46707101

M46708001

M46709001

Wiring Label (12 VDC)

Wiring Label (24 VDC)

Wiring Label (3-Wire Control 12VDC)

Wiring Label (NV with Maintenance Switch)

* Part not shown in Figure 5-1 or Figure 5-2.
