AnsaldoSTS 95 - Parts Lists and Diagrams

Parts List
SM 6495, Rev. 7, December 2008 5-1
5. PARTS LISTS AND EQUIPMENT DIAGRAMS
Table 5-1 is a list of the Model Numbers for the various Model 95 Gate Mechanism configurations.
The list of configurations is dynamic – if you are interested in a configuration that is not listed, please
contact the support team (Section 7).
Table 5-1 - Model 95 Gate Mechanism Configurations
Model Number Description
N46780101 Non-Vital Mechanism
N46780102 Non-Vital Mechanism, 24-Volt
N46780103 Non-Vital Sidewalk Mechanism, RH
N46780104 Non-Vital Sidewalk Mechanism, LH
N46780105 Non-Vital Mechanism with 120 VAC Heater
N46780106 Non-Vital Mechanism with 120 VAC Heater and Maintenance Switch
N46780107 Vital Sidewalk Mechanism, 3-wire control
N46780108 Non-Vital Mechanism with Maintenance Switch
N46780109 Non-Vital Sidewalk Mechanism, RH, with 120 VAC Heater
N46780110 Non-Vital Sidewalk Mechanism, LH, with 120 VAC Heater
N46780111
Non-Vital Sidewalk Mechanism, RH, with 120 VAC Heater and
Maintenance Switch
N46780112
Non-Vital Sidewalk Mechanism, LH, with 120 VAC Heater and
Maintenance Switch
N46780201 Vital Mechanism
N46780202 Vital Gate Mechanism, 24 VDC
N46780204 Vital Gate Mechanism, 3-Wire Control
N46780205 Vital Sidewalk Mechanism, RH, 3-Wire Control
N46780206 Vital Gate Mechanism with Maintenance Switch
N46780207 Vital Sidewalk Mechanism, RH
N46780208 Vital Sidewalk Mechanism, LH
N46780209
Vital Sidewalk Mechanism, RH, with 120VAC Heater and Maintenance
Switch
N46780210
Vital Sidewalk Mechanism, LH, with 120VAC Heater and Maintenance
Switch
N46780301 Non-Vital Pedestrian Mechanism
N46780302 Non-Vital Pedestrian Mechanism with 120 VAC Heater
N46780304 Non-Vital Pedestrian Mechanism with Upgrade Option
N46780305
Non-Vital Pedestrian Mechanism with 120 VAC Heater and
Maintenance Switch
N46780401 Vital Pedestrian Mechanism
N46780402 Vital Pedestrian Mechanism with 120 VAC Heater
N46780403 Vital Pedestrian Mechanism with Upgrade Option
N46780405
Vital Pedestrian Mechanism with 120 VAC Heater and Maintenance
Switch
N46710401 Non-Vital Fail–Up (Exit) Model 95 (Service Manual SM 6495B)
N46710402 Vital Fail-Up (Exit) Model 95 (Service Manual SM 6495B)
N46710406 Non-Vital Fail–Up (Exit) Model 95 (Service Manual SM 6495B)
