AnsaldoSTS 95 - 5.4. Electrical Assembly Parts Lists

Parts List
SM 6495, Rev. 7, December 2008 5-17
5.4. Model 95 Gate Mechanism Electrical Assembly with PN-150 Relay
(12-Volt Systems) (N46782101)
Table 5-5 and Figure 5-10 list the parts for the 12-volt Model 95 gate mechanism electrical assembly
with PN-150 Relay).
Table 5-5 - Parts List for the 12-Volt Electrical Assembly with PN-150 Relay
Item
Number
Part Number Part Description
05 N46701801 Relay Mounting Bracket
10 N4513760301 PN-150 Mounting Base
15 J5001360114 Screw - SS 1/4 - 20 x 7/8 RD
20 J4751210111 Washer, SS Lock No 1/4
25 M038448 Washer
30 J7257150018 Block - Terminal Board Black
35 J7256940169 Circuit Breaker - 12V 20A Reset
N156682
Resistor, Comp for N46782101 only
40
N156683
Resistor, Comp for N46782104 only
42 N156682001 Resistor, Comp
45 M107471 Block, 4-Way Terminal
50 N322505702 Relay, PN-150HD
60 M015577 Washer
65 J4751210108 Washer - SS Lock No 8
70 J5001390114 Screw - SS 1/4-20 x 7/8
75 J5001320128 Screw - 8 - 32 x 1-3/4 SS
80* N46704205 #1 Contact Assembly
85* N46704302 Heel Contact Assembly
90* N46704403 Front Contact Assembly
110* M130200 Terminal Post, AAR
112* M118271 Term Post, AAR
115* M4510113501 Lock Washer
120 J047818 Washer, 17/64 x 9/16 COP, AAR
125 J480300 Nut, 14 - 24 Hex Brass NP, AAR
130 J480301 Nut, 14 - 24 Hex Brass, AAR
135* M4510113402 Washer, Insulating
140* J071626 Link, Test
145* M047290 Connector, #18 x 1/2”
150 N46706702 Harness, PN-150
155 J047521 Washer, high collar lock, 1/4”
160* J075483 Grommet, Rbr Atl. 1919
165 J4802110108 Nut, 1/4 - 20 SS Hex
170 J048145 Nut, 10 - 32 Hex Steel
175 00305047 Washer, #10 Flat
191 J5000970112 Screw, 1/4 – 20 x 3/4 Hex HD SS
200 X46700038 Diode Assembly, Snub Mod. 95
205 J4751820013 Washer, #8 Flat Nylon
265 J7915970003 Screw, 8 - 32 x 3/4 Nylon RH
275 N46712401 Power Down Module
280 J507218 Screw, 1/4 - 20 x 5/8 SS
285 J4751210111 Washer, 1/4 SS Lock
300 N46705602 Diode Assembly, Limit
305 J7355190364 Resistor, 50 Ohm, 5 Watt
