AnsaldoSTS 95 - Page 63

Parts List
SM 6495, Rev. 7, December 2008 5-7
Item
Number
Part Number Part Description
225 J4751200116 Washer, 1/2” Plain Flat
230 J0504980007 Screw, 3/8 - 16 x 2-1/4 Hex SS
235 J050657 Screw, 3/8 - 16 x .500”
240 J4751210113 Washer - SS Lock, 3/8”
245 M46700807 Key, Pedestrian, Gate Arm Gear
250 M46706101 Gear, Pedestrian, Gate Arm
255 M46706201 Gear Clamp, Pedestrian, Gate Arm
260 M46705901 Shaft, Pedestrian, Gate Arm
265 PN46706004 Bearing Support, Pedestrian, Gate Arm
270 J056448003 Bolt - Eye 1/2 – 13 SS
275 J4803170110 Nut, 1/2 - 13 SS Hex
280* J480217 Nut, 1/2” Elastic Stop
285* J0504980011 Screw, Set 3/8” - 16 x 3/4” Cup Point
290 M46705801 Pedestrian Adapter Arm
295 J0504980011 Adapter Arm Set Screw
300 M46700808 Adapter Arm Key 1.5”
305 M46710204 Screw, 1/2 - 20 x 2-1/2
310 00205112 Hex Nut, 18 – 8, 3/8 – 14
315 J4751200114 Washer, SS Plate, 3/8”
320 M46703901 Cam Clamp
* Part not shown in Figure 5-3 through Figure 5-6.
