CIP Objects 76
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Default Values
In case of ADIs containing several elements, that cannot be represented through this object, default val-
ues will be returned, according to the table below.
# Name Value Comments
1 Parameter Value 0 -
2 Link Path Size 0 Size of link path in bytes.
3 Link Path - NULL Path
4 Descriptor 0010h Read only Parameter
5 Data type C6h USINT
6 Data size 1 -
7 Parameter Name String “Reserved” -
8 Units String “” -
9 Help String “” -
10 Minimum value N/A 0
11 Maximum value N/A 0
12 Default value N/A 0
13 Scaling Multiplier N/A 1
14 Scaling Divisor N/A 1
15 Scaling Base N/A 1
16 Scaling Offset N/A 0
17 Multiplier Link N/A 0
18 Divisor Link N/A 0
19 Base Link N/A 0
20 Offset Link N/A 0
21 Decimal Precision N/A 0
