Anybus CompactCom 40 EtherNet/IP User Manual

CIP Objects 75
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Instance Attributes
Extended
# Name Access Type Value
1 Parameter Value Get/Set Specified in attrib-
utes 4, 5 & 6.
Actual value of parameter
This attribute is read-only if bit 4 of Attribute #4 is true
2 Link Path Size Get USINT 0007h (Size of link path in bytes)
3 Link Path Get Packed EPATH 20 A2 25 nn nn 30 05h
(Path to the object from where this parameter’s value is
retrieved, in this case the ADI Object)
4 Descriptor Get WORD Bit:
Contents:
0 Supports Settable Path (N/A)
1 Supports Enumerated Strings
2 Supports Scaling (N/A)
3 Supports Scaling Links (N/A)
4 Read only Parameter
5 Monitor Parameter (N/A)
6 Supports Extended Precision Scaling (N/A)
5 Data Type Get USINT Data type code
6 Data Size Get USINT Number of bytes in parameter value
7 Parameter Name String Get SHORT_STRING Name of the parameter, truncated to 16 chars
8 Units String Get SHORT_STRING “” (default string)
9 Help String Get SHORT_STRING
10 Minimum Value Get
(Data Type)
a
a. The Data Type is defined in attribute 5.
Minimum value of parameter
11 Maximum Value Get
(Data Type)
a
Maximum value of parameter
12 Default Value Get
(Data Type)
a
Default value of parameter
13 Scaling Multiplier Get UINT 0001h
14 Scaling Divisor Get UINT
15 Scaling Base Get UINT
16 Scaling Offset Get INT 0000h
17 Multiplier Link Get UINT
18 Divisor Link Get UINT
19 Base Link Get UINT
20 Offset Link Get UINT
21 Decimal Precision Get USINT 00h
