CIP Objects 94
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Interface Capability
Bit Name Description Implementation
0 Manual setting
requires reset
Indicates whether or not the device requires a reset to apply changes
made to the Interface Control attribute (#6).
0 = Indicates that the device automatically applies changes made to the
Interface Control attribute (#6) and, therefore, does not require a reset
in order for changes to take effect. This bit shall have this value when
the Interface Control attribute (#6) is not implemented.
1 = Indicates that the device does not automatically apply changes
made to the Interface Control attribute (#6) and, therefore, will require a
reset in order for changes to take effect.
Note: this bit shall also be replicated in the Interface Flags attribute
(#2), in order to retain backwards compatibility with previous object
revisions.
Return 0
1 Auto-negotiate 0 = Indicates that the interface does not support link auto-negotiation
1 = Indicates that the interface supports link auto-negotiation
0 for internal interface,
1 for external interfaces
2 Auto-MDIX 0 = Indicates that the interface does not support auto MDIX operation
1 = Indicates that the interface supports auto MDIX operation
0 for internal interface,
1 for external interfaces
3 Manual
speed/duplex
0 = Indicates that the interface does not support manual setting of
speed/duplex. The Interface Control attribute (#6) shall not be sup-
ported.
1 = Indicates that the interface supports manual setting of speed/duplex
via the Interface Control attribute (#6)
0 for internal interface,
1 for external interfaces
4 - 31 Reserved Shall be set to 0 Return 0
