Anybus CompactCom 40 EtherNet/IP User Manual

CIP Objects 93
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Interface State
This attribute indicates the current operational state of the interface.
Admin State
This attribute controls the administrative setting of the interface state.
Interface Label
Interface Type
Value Description
0 Unknown interface state.
1 The interface is enabled and is ready to send and receive data.
2 The interface is disabled.
3 The interface is testing.
Value Description
0 (reserved)
1 Enable the interface.
2 Disable the interface.
3-255 (reserved)
Instance Value
1Port 1
2Port 2
3 Internal
Instance Value Description
1 2 Twisted-pair
2 2 Twisted-pair
3 1 Internal interface
