ConnectBatteryPowerinInstallationswithCables
ConnectPowerCablesBetweentheUPSandtheXRBatteryEnclosure
WARNING:Beforecarryingoutthestepsbelow,thesystemmustbeintotalpower
offandthebatteriesmustberemoved.
WARNING:Eachfreestandingcabinetmustbeseparatelyconnectedtothe
equipotentialbondingsystem(protectiveearthing).
Note:Theterminalsareonlysuitableforconnectionofcoppercables.
5
4
4
7
6
6
6
1
3
2
XR Battery Enclosure
UPS
To XR 2
6
22
Smart-UPS™VT10–30kV A208/220VSingleandParallelInstallation
990–1598E-001
