FinalMechanicalInstallation

ConnectBatterySecuringBracketsforStability

Caution:Waituntilthesystemisreadytobepoweredupbeforeinstallingbatteries.

Failuretodosocanresultinadeepdischargeofthebatteriesandcausepermanentdamage

(thetimefromthebatteryinstallationtimetilltheUPSispoweredupshouldnotexceed

72hoursor3days).

Note:Thebatterysecuringbracketsareonlyusedinnon-seismicareasforstability,and

whenseismicbatterylocksarenotpartoftheinstallation.

1.Installthebatteriesbypushingthemallthewayintotheenclosure.

2.Ifrequired,installthebatterysecuringbrackets(A)toholdthebatteriesrmlyinplace.NOTE:

Donotinstallthebracketsthesamewaytheywerepositionedwhentheenclosurearrived.Rotate

thebrackets180°andreinstall.

Note:BatterysecuringbracketsaredeliveredwiththeUPSandXRBatteryEnclosureand

installedinfrontofthebatteries.Batterysecuringbracketsforadditionalbatteriescanbe

purchased.RefertooptionSUVTOPT003:APCSmart-UPSVTBatteryLockKitforone

BatteryModule(twobatteries).

Smart-UPS™VT10–30kV A208/220VSingleandParallelInstallation

990–1598E-001
