PrepareforCables

RemovetheBatteries

Note:See“RemovetheBatteryModules“forinformationonhowtoremovethebatteries.

RuntheCommunicationCables

Threedifferentwaysofroutingcables

Note:Theenclosuresinaparallelsystemcanbekeptapart,ortheycanbeassembledwith

interconnectionplates.Iftheenclosuresarekeptapart,thecommunicationcablescanberun

inconduits(ifapplicable).

TheroutingofcablesbetweentheUPSunitscanbedoneinthreedifferentways.

•UPSunitsapart(withoutconduitsandwithoutinterconnectionplates)

•UPSunitsbayedtogether(withoutconduitsandwithinterconnectionplates)

•UPSunitsapartorbayedtogether(withconduitsandoptionalinterconnectionplates)

990–1598E-001

Smart-UPS™VT10–30kV A208/220VSingleandParallelInstallation
