ACOutputSpecications
10kV A15kV A20kV A30kV A
208V220V208V220V208V220V208V220V
Connectiontype4-wire(3PH+N+G)
Overloadcapacity150%for1minute(normaloperation)
125%for10minutes(normaloperation)
150%for1minute(batteryoperation)
125%for10minutes(batteryoperation)
110%continuous(bypassoperation)
800%for500ms(bypassoperation)
V oltagetolerance160-240Vfor208Vsystems
160-253Vfor220Vsystems
Nomoutput
current(A)
27.826.241.639.4
55.5
52.583.378.7
Outputfrequency
(synctomains)
50Hz±0.1Hz,±3Hz,±10Hz
60Hz±0.1Hz,±3Hz,±10Hz
Slewrate(Hz/Sec)
0.25-1
TotalHarmonic
Distortion(THD)
<1.5%linear
<3.5%non-linear
Loadpowerfactor0.5leadingto0.5lagging
Dynamicload
response
±5%
Outputvoltage
regulation
±1%
BatterySpecications
Type
VRLA
Nominalvoltage(VDC)+/-192
Floatvoltage(VDC)+/-219
Endofdischargevoltage(VDC)+/-154
Batterycurrent(atfullload)66.5Aat+/-192V
Max.current(atendofdischarge)
83.2Aat+154V
Max.chargingpower10kV A:1600W
15kV A:2400W
20kV A:3200W
30kV A:3200W
Typicalre-chargetime5hours
Endvoltage1.6-1.75V/cell(automatic,dependingonload)
990–1598E-001
Smart-UPS™VT10–30kV A208/220VSingleandParallelInstallation
3

APC Smart-UPS VT Specifications

General

Noise level	55 dB
Output power	24000 W
Input frequency	40/70 Hz
Maximum current	41 A
Output power capacity	30 kVA
Emergency Power Off (EPO)	Yes
Battery type	VRLA
Dimensions (WxDxH)	559 x 813 x 1499 mm
Nominal input voltage	400 V
Certification	C-tick, CE, EN 50091-2, EN/IEC 62040-3, IEC 61000-3-2, IEC 61000-3-3, ISO 14001, ISO 9001, VFI-SS-112
Product color	Black
Battery recharge time	5 h
Operating altitude	0 - 999.9 m
Non-operating altitude	0 - 15000 m
Storage temperature (T-T)	-15 - 45 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	85078000

Weight and Dimensions

Weight	629090 g
Package weight	660000 g
