TEST SETTING PARAMETERS Cont.
310XAC
320XAC
340XAC
360XAC
Power Lo-Lmt
0.0 W - 1000 W,
0 = OFF
0.0 W - 2000 W,
0 = OFF
0.0 W - 4000 W,
0 = OFF
0.0 W - 6000 W, 0 =
OFF
Power Apparent Hi-
Lmt
0.0 VA - 1000 VA,
0 = OFF
0.0 VA - 2000
VA, 0 = OFF
0 VA - 4000 VA,
0 = OFF
0 VA - 6000 VA,
0 = OFF
Power Apparent Lo-
Lmt
0.0 VA - 1000 VA,
0 = OFF
0.0 VA - 2000
VA, 0 = OFF
0 VA - 4000 VA,
0 = OFF
0 VA - 6000 VA,
0 = OFF
Power Reactive Hi-
Lmt
0.0 VAR - 1000
VAR, 0 = OFF
0.0 VAR - 2000
VAR, 0 = OFF
0 VAR - 4000
VAR, 0 = OFF
0 VAR - 6000 VAR,
0 = OFF
Power Reactive Lo-
Lmt
0.0 VAR - 1000
VAR, 0 = OFF
0.0 VAR - 2000
VAR, 0 = OFF
0 VAR - 4000
VAR, 0 = OFF
0 VA - 6000 VA,
0 = OFF
Power Factor Hi-Lmt
0.000 - 1.000, 0 = OFF
Power Factor Lo-Lmt
0.000 - 1.000
Crest Factor Hi-Lmt
0.00 - 10.00, 0 = OFF
Crest Factor Lo-Lmt
0.00 - 10.00
Timer Unit
Second, Minute, Hour
Ramp Up
Range
AC
0.00 - 999.9
DC
1.0 - 999.9, 0 = OFF
Resolution
0.1 (second, minute, hour)
Accuracy
± (0.1% + 0.05 sec.)
Delay
Range
0.5sec - 999.9 sec (1.0 – 999.9 when linked), 0.1 min - 999.9 min, 0.1 hr - 999.9 hr
Resolution
0.1 (second, minute, hour)
Accuracy
± (0.1% + 0.1 sec)
Dwell
0.5 - 999.9 (1.0 – 999.9 when linked), 0 = Constant
Resolution
0.1 second, minute, hour
Accuracy
± (0.1% + 0.1 sec)
Ramp Down
Range
AC
0.5 - 999.9
DC
1.0 - 999.9, 0 = OFF
Resolution
0.1 (second, minute, hour)
Accuracy
± (0.1% + 0.05 sec.)
Phase Setting
Linking
A/B/C 3Φ4W (120º), L1 - N & L2 - N 1Φ3W (180º)
Prompt
Alphanumeric
Start Angle
0º - 359º
End Angle
0º - 359º
Start & End Angle
Resolution
1º
Accuracy
±1% (45 Hz - 65 Hz)
Connect
ON, OFF
Transient
ON, OFF (Only 40 Hz - 70 Hz is available)
Trans-Volt
0.0 V - 300.0 V
Trans-Site
0.0 - 25.0 msec
Trans-Time
0.5 - 999.9 msec
Trans-Cycle
0-9999, 0=Constant
