APT 300XAC Series User Manual

23
SYSTEM
PARAMETERS
310XAC
320XAC
340XAC
360XAC
Auto Run
Program, Manual
Output Mode
Manual
AC, DC
Single Step
Program
ON, OFF
Alarm
0 - 9, 0 = OFF, 9 = High
Contrast
1 - 9, 9 = High
Power Up
ON, OFF, LAST
Loop Cycle
Program
0 - 9999, 0 = Cont., 1 = OFF
Results
LAST, P/F, ALL
OC Fold
ON, OFF; response time < 1.4 seconds
Transient
Manual
ON, OFF
Lock
ON, OFF
Mem Lock
ON, OFF
Volt Sense
INT, EXT
Synch Signal
START, EVENT, OFF, 5 V DC Signal
Linking
AUTO DETECT (Parallel, 1Φ3W, 3Φ4W)
Re-Config
YES, NO
Address
IP, GPIB, RS-485
GENERAL
310XAC
320XAC
340XAC
360XAC
Safety Agency Listing
CE, cTUVus, RoHS2
Enhanced Over Load Capacity
Over current 110% can hold for 1000 ms without protection
Operation Key
Feature
Soft key, Numeric Key, Rotary Knob
Remote Output
Signal
Output (Pass, Fail, Test in Process)
Calibration
Front Panel
Key Lockout
Soft Key & Password Protected
Synch Output Signal
5 V DC
Graphic Display
260 x 64 Mongraphic, LCD
Interface
USB/RS-232, Optional GPIB or Ethernet
Barcoding
Barcode Capable
Protection Circuit
Over Current, Over Temperature, Over Power, Over Voltage
Fan
Temperature Controlled
Rear Output
Terminal Block
Rack Mount Handles
Standard
No Caster Wheels
PFC
97% at Full Load
Efficiency
75% at Full Load
80% at Full Load
CE Mark
Yes
Parallel/Poly-Phase Output
Multiple Source Linking: L1 - N & L2 - N 1Φ3W (180º), A/B/C 3Φ4W (120º)
Operation
Environment
0 - 40ºC / 20 - 80% RH
Dimensions
430 (W) x 133.5 (H) x 530 (D) mm
430 (W) x 267
(H) x 500 (D) mm
430 (W) x 400.5 (H) x
500 (D) mm
Net Weight
21 Kg
22 Kg
37 kg
53 Kg
