100 CS175-275-575-875 Installation Guide
Terminal Description
POS
Connect to the KP POS terminal of the CSx75. Current draw is 30 mA.
COM
Connect to the KP GND terminal of the CSx75.
DATA
Connect to the KP DATA terminal of the CSx75.
17.3.2 Specifications
Operating power
12 VDC supplied from CSx75.
Compatibility
Compatible with CS175-275-575-875
Frequency
868 MHz for the RX8w8 and RX16w8
Current draw
30 mA maximum
Operating temperature
0 to 49°C
Dimensions
11 cm wide x 8.1 cm high x 2.54 cm deep
Shipping weight
105 g
17.4 Programming the RX8w8 – RX16w8
In order to program the RX8w8 – RX16w8 you must do the following:
•
Determine the transmitter settings: determine the different settings for the wireless
sensors.
•
Enroll the modules: set-up the module to be supervised by the CSx75 control panel.
•
Program the module: put the module into program mode so you start programming
the transmitters and enter the settings for transmitters and partitions.
17.4.1 Receiver installation and procedure (for Belgium)
The RX9008 antenna kit fits the RXxxW8 dual antenna receiver family. It is used
during installation, commisioning and testing of the wireless security system. Its
purpose is to ensure a sufficient margin in signal strength during normal operation by
reducing the receiver sensitivity during installation and maintainance checks.
Steps
1. Install the system.
2. Replace both receiver antennas with the RED RX9008 antennas.
3. Power-up and learn in all the transmitters.
4. Relocate transmitters with bad reception if necessary.
5. After succesful installation, remove the RX9008 antennas and re-install the
original receiver antennas.
