CS175-275-575-875 Installation Guide 15
INSTALLING THE CONTROL UNIT
4.4.1 CS575M/CS875M (large metal housing)
This large metal housing can be used with the CS575 and CS875.
Steps
1. Open the box.
2. Wire the panel.
3. Attach the ribbon cable to the CS534 listen-in module.
4. Connect the CS534 listen-in module and CS535 voice module with the ribbon cable.
5. Add the pillars for the CS535 voice module to the board.
6. Attach the CS535 voice module to the board via the jumpers and pillars.
7. Attach the pillars for the CS534 listen-in module to the box.
8. Insert the CS534 listen-in module in the box.
