CS175-275-575-875 Installation Guide 101
17.4.2 Programming the zone configuration and partition
All zones are programmed via the CSx75 panel and keypad. For instructions on accessing
and programming the CSx75, as well as changing the characteristics of a configuration
group, consult the CSx75 Installation Manual.
Location 0 Learn-in mode
This location is used to learn in devices. The segment used refers to the zone number
required.
Location 1 to 168 Transmitter features (two segments, FSD)
These locations contain two segments for transmitter specific functions.
Segment 1 1
Transmitter enabled (Default =On)
2
Transmitter supervised (Default =On)
3
User Fire (smoke)
supervision windows
Default =Off)
4
Reserved
5
Reserved
6
Reserved
7
Reserved
8
Reserved
Segment 2 1
Partition 1 keyfob (Default =On)
2
Partition 2 keyfob (Default =On)
3
Partition 3 keyfob (Default =On)
4
Partition 4 keyfob (Default =On)
5
Partition 5 keyfob (Default =On)
6
Partition 6 keyfob (Default =On)
7
Partition 7 keyfob (Default =On)
8
Partition 8 keyfob (Default =On)
Location 193 Receiver features (one segment, FSD)
Segment 1 1
On: jam detection enabled.
2
On: sequential programming method enabled.
3-8
Not used
