17.1 Setting the DIP switches
Decide the starting zone of each zone expander. The starting zone must be on a
boundary of eight zones. The eight or 16 zones for the module move out from this starting
position.
To set the starting zone, set the DIP switch according to the table below.
"
The position of all switches is updated only when the RX8w8-16w8 is powered up. Before
you change the position of these switches you must power down the expander.
Some RX8w8 and RX16w8 receivers have DIP Switches labels with On/Off rather than
Open/Closed labels. The following table lists both references. The label on the receiver
always refers to Open/Close(O/C).
Module Number DIP Switch 1 DIP Switch 2 DIP Switch 3 DIP Switch 4
34
C (On) C (On) C (On) Not Used
33
O (Off) C (On) C (On) Not Used
32 (Default)
C (On) O (Off) C (On) Not Used
39
O (Off) O (Off) C (On) Not Used
38
C (On) C (On) O (Off) Not Used
37
O (Off) C (On) O (Off) Not Used
36
C (On) O (Off) O (Off) Not Used
35
O (Off) O (Off) O (Off) Not Used
17.2 Module Status Conditions
When you apply power to the CSx75, the LED (red) should start blinking. The following
table defines the different states of the red and green LEDs.
LED Module Status
Red blinking
Red off
Normal data communication with the CSx75.
No data communication with the CSx75, check the wiring and
power source.
Green blinking
Green off
Receiving radio signals from learn mode wireless sensors.
No radio signals currently being received.
17.3 Wiring the RX8w8-16w8
Wire the bus according to the table below.
17.3.1 Terminal description
