56
CS175-275-575-875 Installation Guide
13 PROGRAMMING WITH UP/DOWNLOAD SOFTWARE
13.1 General
You can program the CSx75 using the LED keypad, the LCD keypad or the UDx75
software. This software allows you to download the programming information on the
control panel to the computer running the UDx75 software, change it and upload the
changes from the computer to the panel. It also allows you to view the program log and
event log. To program the system using this software, you must connect the control panel
to the computer.
You can connect the control panel to the computer either directly via the RS232 serial
port or remotely via a modem.
13.1.1 Wiring of the RS232 cable
Three wires are needed for the communication: RX, TX and GND.
13.2 Programming
Ensure the up/download access code is the same in both the up/download software and
the control panel. See the table of country codes on page 10 for the correct default value.
In the control panel, you must program the locations listed in the following table.
Location Value
Location 207: Serial Port
Segment 1: 1 = Home Automation
Location 208: Speed
Segment 1: 2 = 9600 baud
Location 209: Protocol
Segment 1: 0 = Binary
Location 210:
Segment 1: --------
Segment 2: --------
Location 211:
Segment 1: 12345678
Segment 2: 12345678
Segment 3: 12345678
Segment 4: 12345678
For the white connector.
CS575 DB 9 Connector DB 25 Connector
1 ( Closest to phone line)
2 3
2
3 2
4 (Closest to the Mains )
5 7
