128 CS175-275-575-875 Installation Guide
Signal Name CS175 ------ PC Jumper
number
Pin number
A position
Pin number
B position
TXS
- > J8 2 3**
RTS*
<- J9 8 7**
RXD
<- J10 2** 3
Sig.Gnd.
< - > - 5 5
Unused
-- - 1,4,6,9 1,4,6,9
"
*Rts and Cts signals are not currently supported
**Default jumper settings
21.1.2 Specifications
Operating power
12 VDC supplied from CSx75
Current
30 mA
Operating temperature
0 to 49°C
Dimensions
10 x 8.2 x 2.54 cm (width x length x depth)
Shipping weight
150 g
21.2 General operating instructions
21.2.1 LED Indications
•
DS1 Flashes for CSx75 bus.
• DS3 Flashes for each valid packet received from host.
•
DS4 Flashes for each packet transmitted to host.
•
DS5 On when waiting for CSx75 function to be completed.
•
DS6 On when waiting for acknowledgement from host.
21.3 Programming the CS586
21.3.1 Programming the RS232 parameters
All zones are programmed via the CSx75 panel and keypad. See the CSx75 Installation
Manual for information on accessing and programming the CSx75 and changing the
characteristics of a configuration group.
