CS175-275-575-875 Installation Guide 149
25 APPENDIX 3: OVERVIEW OF MODULE NUMBERS
Every keypad, expansion module and wireless receiver module has a module number.
The following tables list the different module numbers.
Device Device # reported
Control panel 0
CS534 Two-way Listen-In 64
25.1 Keypads
Keypad Part1 Part2 Part3 Part4 Part5 Part6 Part7 Part8
1
192 193 194 195 196 197 198 199
2
200 201 202 203 204 205 206 207
3
208 209 210 211 212 213 214 215
4
216 217 218 219 220 221 222 223
5
224 225 226 227 228 229 230 231
6
232 233 234 235 236 237 238 239
7
240 241 242 243 244 245 246 247
8
248 249 250 251 252 253 254 255
25.2 Hardware expander CS216
Starting zone number
Expander #
reported
Starting zone number
Expander #
reported
Zone 41 (Switch 1 & 3 on) 19 Zone 105 (Switch 1, 3 & 4 on) 101
Zone 49 (Switch 2 & 3 on) 20 Zone 113 (Switch 2, 3 & 4 on) 102
Zone 57 (Switch 1, 2 & 3 on) 21 Zone 121 (Switch 1, 2, 3 & 4 on) 103
Zone 65 (Switch 4 on) 96 Zone 129 (Switch 5 on) 104
Zone 73 (Switch 1 & 4 on) 97 Zone 137 (Switch 1 & 5 on) 105
Zone 81 (Switch 2 & 4 on) 98 Zone 145 (Switch 2 & 5 on) 106
Zone 89 (Switch 1, 2 & 4 on) 99 Zone 153 (Switch 1, 2 & 5 on) 107
Zone 97 (Switch 3 & 4 on) 100 Zone 161 (Switch 3 & 5 on) 108
25.3 Output module CS507
