CS175-275-575-875 Installation Guide 33
7 WIRING SOUNDERS
7.1 Wiring a sounder with EOL protection
Any zone can be used. It should be programmed as tamper and single EOL.
7.2 AS500
CSx75
AS500
1
Beacon hold off
5
Tamper
9
Piezo
2
Siren hold off
6
Tamper
10
Piezo
3
+13.8 V
7
Beacon
11
Piezo
4
GND
8
Beacon
"
In all cases, select negative hold off on the sounder.
DATA AUX+ COM
I
N
T
COM E
X
T
R1NC R1NO
R
1
C
A
U
X
+
OUT2 COM R
3
N
C
R
3
N
O
R
3
C
AUX+ COM O
U
T
4
TAM PER T
A
M
P
E
R
Z
1
COM Z2 Z
3
C
O
M
Z4 Z
5
COM Z
6
Z7 COM Z8
4K7
4K7
9 8 7 6 5 4 3 2 10 1 11
4K7
