Aritech CS875 User Manual

CS175-275-575-875 Installation Guide 121
20.3 Programming the CS507
20.3.1 Programming the output configuration and partition
Location 0 Programming the event, zone and time for output 1 (three segments, ND)
This location is used to select the particular function, zone number and time for an output
to trip.
Segment 1 (EVENT)
Selects the event that triggers the output. See the table
below for the specific events that can be selected.
Segment 2 (ZONE/USER)
Selects the zone or user number necessary to trigger an
output. If 0 is programmed in this location, any zone or user
activates the output.
Segment 3 (TIME)
Selects the amount of time an output remains activated
when an output triggers. If 0 is programmed in this location,
the output follows the particular event.
# Event # Event # Event
0 
Burglary Alarm
18
Entry
36
Program Mode
1 
Fire Alarm
19
Exit
37
Download
2 
24-hour Alarm
20
Entry or Exit
38
Ground Fault
3 
Zone Trouble
21
Armed
39
Over Current
4 
Zone Tamper
22
Not Armed
40
Box Tamper
5
Burglary Siren
23
Ready
41
Siren Tamper
6
Fire Siren
24
Not Ready
42
Any Zone Faulted
7
Any Siren
25
Fire
43 
Any Alarm
8
Zone Bypass
26
Fire Trouble
44
Keypad Beeping
9
AC Failure
27
Chime
45 
Code Entry
10
System Low Battery
28 
Expander Trouble
46 
Key FOB Function 1
11 
Duress
29
Dynamic Battery Test
47 
Key FOB Function 2
12 
Manual Fire
30
Open Schedule 
48
Auto Arm Control
13 
Aux 2 Keypad
31
Closed Schedule 
49
Auto Disarm Control
14 
Keypad Panic
32
Listen In
50
Auto Arm and Disarm Control
15
Keypad Tamper
33
Line Seizure
51
Follow schedule of CS507
16 
Automatic Test
34
Failed to Communicate
52
Flash X-10 for Alarm Memory
17
Alarm Memory
35
Telephone Line Fault
53
Flash X-10 for Siren
 See loc. 65 and 66 in CSx75
