122
CS175-275-575-875 Installation Guide
If set to follow condition, these events is 1 second.
Events 46 and 47 require RX8i4 - RX16i4 wireless receivers to operate.
Events 48, 49 and 50 arm or disarm the CSx75 at the open (disarm) or close (arm) time for the appropriate
schedule.
"
For events 48 and 50, the keypad buzzer sounds one minute prior to auto arm if the zone
value is 1. If the zone value is 0, the keypad does not sound prior to auto arm.
Location 1 Programming special functions and partitions for output 1 (two segments, FSD)
Segment 1 Selects the following special conditions:
1
On: output times in minutes
Off: output times in seconds.
2
On: output latches until a code is entered.
3
On: output resets if a code is entered while it is being timed.
4
On: output only triggers during a closed schedule.
5
On: output only triggers during an open schedule.
6
On: output is inverted.
7
On: a trigger is logged in the event buffer.
Segment 2 Selects the following partitions:
1
On: the event activates when it occurs in partition 1.
2
On: the event activates when it occurs in partition 2.
3
On: the event activates when it occurs in partition 3.
4
On: the event activates when it occurs in partition 4.
5
On: the event activates when it occurs in partition 5.
6
On: the event activates when it occurs in partition 6.
7
On: the event activates when it occurs in partition 7.
8
On: the event activates when it occurs in partition 8.
Location 2 Enabling the schedules for output 1 (one segment, FSD)
This location is used to enable any or all of the eight schedules. Segment 1 corresponds
to schedule 1 and segment 8 corresponds to schedule 8. This location can be used in
conjunction with the special function location to create an output that activates only during
certain times and/or certain days.
Segment 1 1
On: the event follows schedule 1.
2
On: the event follows schedule 2.
3
On: the event follows schedule 3.
