98 CS175-275-575-875 Installation Guide
17 SETTING UP RF ZONES – RX8W8-16W8
The RX-Series receiver modules adds 868 MHz wirelless capabilities to a CSx75
controller. There are eight zones for an RX8w8 and 16 zones for an RX16w8. Adding a
receiver module makes a CSx75 control panel compatible with the RX wireless
transmitters and keychain touchpads or keyfobs.
1
Jumper setting
5
Bus supervision LED
9
Jumper setting
2
Lid tamper
6
Keypad bus connectionn
10
Processor
3
Eeprom
7
Not used
11
DIP switches
4
Wireless communication
LED
8
Antenna
RX8w8-16w8
ANT 1
ANT 2
IC7
J2
J1
IC10
D1
D2
ON
1234
11
9
8
7
6
5
4
3 2 1
10
DATA
COM
POS
