CS175-275-575-875 Installation Guide 117
Location 5 Programming X-10 address for output 1 (two segments, ND)
"
An X-10 interface module, such as the CS534, must be present for this feature to work
properly.
Segment 1
Module number (Default = 0)
Contains the X-10 module number. Program a number from 0 to 15 to
represent the corresponding X-10 module number from the following
table.
Module #
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Seg 1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Segment 2
House code (Default = 0)
Contains the X-10 house code. Program a number from 0 to 15 to
represent the corresponding X-10 house code from the following table.
0 = A 4 = E 8 = I 12 = M
1 = B 5 = F 9 = J 13 = N
2 = C 6 = G 10 = K 14 = O
X-10
ADDRESS
CODES
3 = D 7 = H 11 = L 15 = P
Location 6 to 13 Programming X-10 Address for outputs 2 to 9 (two segments , ND)
These locations are used to program the X-10 address for outputs 2 – 9. Each location
has two segments. Segment 1 contains the module number and segment 2 contains the
house code. See
Location 5
above for more information.
