140
CS175-275-575-875 Installation Guide
Seg#1-2:
0-0
202
Characteristic select
203
SIA Code: Group 20
204
4/2 alarm code
Seg#1-2-3:
0-0-0
205
4/2 restore
Seg#1-2:
0-0
206
Characteristic select
207
Serial port enable
0 = Serial STU
1 = Home automation protocol enabled (CS586)
2 = Serial printer
208
Serial port baud rate
0= 2400 (2.4K)
1=4800 (4.8K)
2=9600 (9.6k)
3=19200 (19.2K)
4=38400 (38.4K)
5-7=Reserved
209
Home automation protocol
LED off = binary
LED on = ASCII
210
Transition based broadcasts
Seg#1
Seg#2
1 = Reserved
2 = Interface configuration
3-4 = reserved
5 = zone status
6 = zone snapshot
7 = Partition status
8 = Partitions snapshot message
1 = System status message
2 = X-10 message received
3 = Log event message
4 = Keypad message received
5-8 = Reserved
211
CS586 Command/request enable
Seg#1
Seg#2
1 = Reserved
2 = Interface configuration request
3 = Reserved
4 = Zone name request
5 = Zone status request
6 = Zone snapshot request
7 = Partition status request
8 = Partitions snapshot request
1 = System status request
2 = X-10 message message
3 = Log event request
4 = Send keypad text message
5 = Keypad terminal mode req
5-8 = Reserved
Seg#3
Seg#4
1 = Program data request
2 = Program data command
3 = User info request with PIN
4 = User info request without PIN
5 = Set user code command with PIN
6 = Set user code command w/o PIN
7 = Set user authoriz comm with PIN
8 = Set user authoriz comm w/o PIN
1-2 = reserved
3 = Store communication event command
4 = Set clock/calendar command
5 = Primary keypad function with PIN
6 = Primary keypad function w/o PIN
7 = Secondary keypad function
8 = Zone bypass toggle
212
LCD keypad address for CS586: See Appendix 3 for more information.
213
Zones 49-56, zone types
1-1-1-1-1-1-1-1
214
Zones 49-56, partition selection (Segment 1=zone 49 to segment 8=zone 56)
Segments Part#1 Part#2 Part#3 Part#4 Part#5 Part#6 Part#7 Part#8
Seg#1 (49)
1
Seg#2 (50)
1
