CS175-275-575-875 Installation Guide 73
Location 57 Auxiliary output 1 to 4 partition selection (four segments, FSD)
This location is used to select the partition(s) in which events must occur before the output
activates. This location has four segments. Segment 1 corresponds to output 1 and
segment 4 corresponds to output 4.
Segment 1 (Aux 1) Segment 2 (Aux 2) Segment 3 (Aux 3) Segment 4 (Aux 4)
1= Partition #1 1= Partition #1 1= Partition #1 1= Partition #1
2= Partition #2 2= Partition #2 2= Partition #2 2= Partition #2
3= Partition #3 3= Partition #3 3= Partition #3 3= Partition #3
4= Partition #4 4= Partition #4 4= Partition #4 4= Partition #4
5= Partition #5 5= Partition #5 5= Partition #5 5= Partition #5
6= Partition #6 6= Partition #6 5= Partition #6 5= Partition #6
7= Partition #7 7= Partition #7 7= Partition #7 7= Partition #7
8= Partition #8 8= Partition #8 8= Partition #8 8= Partition #8
Location 58 Auxiliary output 1 to 4 special timing (four segments, FSD)
This location contains the special timing feature activation for the four auxiliary outputs.
Segment 1 corresponds to output 1 and segment 4 corresponds to output 4.
Segment 1-4 1
On: output is timed in minutes; Off: outputis timed in seconds.
2
On: output latches; Off: output is timed.
3
On: output stops timing upon code entry; Off: output continues to
time upon code entry.
4
On: output activates only between the closing and opening time
in locations 65 and 66.
5
On: output activates only between the opening and closing time
in locations 65 and 66.
6
On: output is inverted (0 volts going to 12 volts when activated).
7-8
Reserved
Location 59 Auxiliary output #1, event and time (two segments, ND)
Segment 1
Use the table below to select the event that activates auxiliary output
1.
Segment 2
Program the timing from 0 to 255 (minutes or seconds, depending on
data programmed in segment 1, location 58). Program a 0 to make
the output follow the event.
Data Event Data Event
Alarms Armed/Disarmed
0
Burglary alarm
21
Armed state
