84
CS175-275-575-875 Installation Guide
6
Primary keypad function without PIN
7
Secondary keypad function
8
Zone bypass toggle
Location 212 LCD keypad address for CS586 (one segments, ND)
See
Appendix 3
for a list of keypad module numbers.
Location 213 Zone type, zones 49 to 56 (eight segments, ND)
This location contains the zone type for zones 49 to 56. Segment 1 corresponds to zone
49 and segment 8 corresponds to zone 56. See
Location 36
on page 67
for more
information.
Location 214 Partition select, zones 49 to 56 (eight segments, FSD)
This location is used to select the partition(s) in which zones 49 to 56 reside. A zone may
reside in any combination of the eight partitions. See
Location 37
on page 67 for more
information.
Location 215 Zone type, zones 57 to 64 (eight segments, ND)
This location contains the zone type for zones 57 to 64. Segment 1 corresponds to zone
57 and segment 8 corresponds to zone 64. See
Location 36
on page 67
for more
information.
Location 216 Partition select, zones 57 to 64 (eight segments, FSD)
This location is used to select the partition(s) in which zones 57 to 64 reside. A zone may
reside in any combination of the eight partitions. See
Location 37
on page 67 for more
information.
Location 217 Zone type, zones 65 to 72 (eight segments, ND)
This location contains the zone type for zones 65 to 72. Segment 1 corresponds to zone
65 and segment 8 corresponds to zone 72. See
Location 36
on page 67
for more
information.
Location 218 Partition select, zones 65 to 72 (eight segments, FSD)
This location is used to select the partition(s) in which zones 65 to 72 reside. A zone may
reside in any combination of the eight partitions. See Location 37 on page 67 for more
information.
Location 219 Zone type, zones 73 to 80 (eight segments, ND)
This location contains the zone type for zones 73 to 80. Segment 1 corresponds to zone
73 and segment 8 corresponds to zone 80. See
Location 36
on page 67
for more
information.
Location 220 Partition select, zones 73 to 80 (eight segments, FSD)
This location is used to select the partition(s) in which zones 73 to 80 reside. A zone may
reside in any combination of the eight partitions. See
Location 37
on page 67 for more
information.
