Level One Memory System
ARM DDI 0363G Copyright © 2006-2011 ARM Limited. All rights reserved. 8-11
ID073015 Non-Confidential
background fault might indicate a stack overflow, and be rectified by allocating more stack and
reprogramming the MPU to reflect this. Alternatively, an asynchronous external abort might
indicate that a software error meant that a store instruction occurred to an unmapped memory
address. Such an abort is fatal to the system or process because no information is recorded about
the address the error occurred on, or the instruction that caused the error.
Table 8-1 shows which types of abort are typically fatal because either the location of the error
is not recorded or the error is unrecoverable. Some aborts that are marked as not fatal might turn
out to be fatal in some systems when the cause of the error is determined. For example, an MPU
background fault might indicate a stack overflow, that can be rectified, or it might indicate that,
because of a bug, the software has accessed a nonexistent memory location, that can be fatal.
These cases can be distinguished by determining the location where the error occurred. If an
error is unrecoverable, that is, it is not a correctable parity or ECC error, and it is not a TCM
external retry request, it is normally fatal regardless of whether or not the location of the error
is recorded. When an abort is taken on an external TCM, parity, or ECC error, the appropriate
Auxiliary Fault Status Register records whether the error was recoverable. See Fault Status and
Address Registers on page 4-47.
Correctable errors
In a system in which the processor is configured to automatically correct ECC errors without
taking an abort exception, you can still configure it to respond to such errors. Connect the event
output or outputs that indicate a correctable error to an interrupt controller. When such an event
occurs, the interrupt input to the processor is set, and the processor takes an interrupt exception.
When your interrupt handler has identified the source of the interrupt as a correctable error, it
can read the CFLR to determine where the ECC error occurred. You can examine this
information to identify trends in such errors. By masking the interrupt when necessary, your
software can ensure that when critical code is executing, the processor corrects the error
automatically, but delays examining information about the error until after the critical code has
completed.
Table 8-1 Types of aborts
Type Conditions Source Synchronous Fatal
MPU fault
Access not permitted by MPU
a
MPU Yes No
Synchronous External Load using L2 memory interface AXI Yes No
Asynchronous External Store to Normal or Device memory using L2 memory
interface
AXI No Yes
Synchronous Parity/ECC Cache
Load from cache
b
Cache Yes
Maybe
c
Synchronous Parity/ECC TCM
Load/store from/to TCM
d
TCM Yes
Maybe
c
Synchronous TCM external error
Load/store from/to TCM
e
TCM Yes Yes
Asynchronous Parity/ECC Cache
Store to cache or cache maintenance operation
b
Cache No
Maybe
c
Asynchronous TCM external error
Store to TCM
e
TCM No Yes
a. See MPU faults on page 7-10 for more information about the types of MPU fault.
b. See Cache error detection and correction on page 8-20 for more information about parity/ECC errors from the cache.
c. These types of error can be correctable or uncorrectable. Uncorrectable errors are typically fatal. Correctable errors are automatically
corrected by the hardware and might not cause the abort handler to be called. See Cache error detection and correction on page 8-20 and
TCM internal error detection and correction on page 8-14.
d. See TCM internal error detection and correction on page 8-14 for more information about parity/ECC errors from the TCM.
e. Aborts generated by external TCM errors are always unrecoverable, and therefore fatal, see External TCM errors on page 8-16 for more
information about external errors from the TCM.
