52
ARRIGLOW
Attaching ARRIGLOW
The ARRIGLOW module is available as an option. It allows
illuminated format markings to be superimposed onto the
viewfinder image with continuously adjustable brightness.
• Loosen both fastening screws ➪ photo on the warning
display module.
• Pull the warning display module off sideways.
Attach the ARRIGLOW module straight.
Attaching at an angle could damage the plug.
• Push on the ARRIGLOW module ➪ photo.
• Screw both fastening screws tight.
Adjusting ARRIGLOW Brightness
The brightness of the illuminated format markings can be
continuously adjusted by turning the adjustment knob
➪ photo.
By turning the adjustment knob counter-clockwise as far
as it will go, the ARRIGLOW can be turned off.
Optics
fastening
screws
ARRIGLOW module
