Mode 9
In this mode the external control configuration of the
camera can be selected when the MCI-1 module is
mounted on the right side of the camera:
mode maximum speed maximum acceleration capping shutter notes
SD1 96fps (150 fps) 40f/s
2
(100 f/s
2
) open shutter and transport internally synchronized
adjustable sector has to be set in camera
SD2 96fps (150 fps) 40f/s
2
(100 f/s
2
) open shutter and transport internally synchronized
adjustable sector can be controlled externally
SD3 96fps (150 fps) 40f/s
2
(100 f/s
2
) open shutter and transport phase can be adjusted externally
adjustable sector can be controlled externally
SDCS1 96fps (150 fps) 40f/s
2
(100 f/s
2
) external control shutter and transport internally synchronized
adjustable sector has to be set in camera
the capping shutter can be controlled externally
SDCS2 96fps (150 fps) 40f/s
2
(100 f/s
2
) external control shutter and transport internally synchronized
adjustable sector can be controlled externally
the capping shutter can be controlled externally
SDCS3 96fps (150 fps) 40f/s
2
(100 f/s
2
) external control shutter and transport phase can be adjusted externally
adjustable sector can be controlled externally
adjustable sector can be controlled externally
the capping shutter can be controlled externally
CAN1 150fps 100f/s
2
external control ARRIMOTION only
CAN2 150fps 100f/s
2
external control ARRIMOTION only
CAN3 150fps 100f/s
2
external control ARRIMOTION only
Camera Operation
Note: For further information on the maximum speed
and acceleration limits see page 70.
