Lower Shutter
144 FastPak EXP Operating Manual
Lower Shutter
The lower shutter, also known as the second shutter,
is located beneath the hopper. Open the front access
doors, turn off the power, and gently pull out the
printing and packaging assembly tray.
Figure 8-17 Locating the lower shutter
You need not remove the plastic top of the lower
shutter to clean it. Simply vacuum or wipe the
plastic top and interior surfaces with a clean, dry,
lint-free cloth each day.
Remove the plastic top weekly for cleaning. Gently
lift off the plastic top to access the lower shutter.
Vacuum or wipe off the plastic top and interior
surfaces of the lower shutter with a clean, dry, lint-
free cloth.
