Connecting to a Power Source
20 FastPak EXP Operating Manual
4. Connect one of the keyboard connectors to one
of the synapse cable connectors from the scanner.
Note that the connectors will only fit together
one way.
5. Connect the remaining connector from the
keyboard to the mouse port on the PC.
6. Connect the remaining connector from the
synapse cable to the keyboard port on the PC.
Connecting to a Power Source
Plug the PC and touchscreen into an uninterruptible
power supply (UPS) rated for a minimum of 650
watts. Plug the uninterruptible power supply (UPS)
and the FastPak EXP power cord into a three-prong
grounded (earthed) electrical outlet (wall socket) that
is easily accessible from the intended operating
location.
Do not use a three-prong to
two-prong adapter.
Do not use an extension cord if
the intended outlet is too far
from the intended location.
Move the device so that it is
closer to the outlet or have
another electrical outlet
installed.
