Perforation Blade Assembly
148 FastPak EXP Operating Manual
To adjust the perforation blade, do the following:
1. Lift off the perforation blade assembly.
Figure 8-20 Removing the perforation blade
assembly
2. Loosen the adjustment screw indicated in the
image below, with an Allen wrench, to adjust the
position of the perforation blade. Retighten
when you have repositioned the blade to your
satisfaction.
Spindle on which
the perforation blade
assembly resides
