Handset Configuration
CONFIGURATION MANUAL
Ascom d83 DECT Handset
3. From the pull down menus associated with each parameter, select the required values for:
− Ring volume: Select “Silent” or one of the volume levels between 1, the lowest, and 8, the highest.
− Vibrating alert: Select “On” or “Off”.
− Internal call: A ringtone to indicate an internal call.
− External call: A ringtone to indicate an external calls.
− Callback: A ringtone to indicate a callback.
− PTT Call: A ringtone to indicate a Push-to-talk call.
− Key sound: Select “Silent” or associate the key press with a “Click” or “Tone”.
− Message alert: Indicate an incoming message by a melody, beeps or a customized sound.
− Message volume: For an incoming message, set the alert to the same volume level as for Ring
volume or set a higher or lower volume.
5.45.2.4 Configure Soft key groups (sub group)
Select System Profiles → System Profiles Sub Groups → Soft key groups → Soft key group X → Soft key X.
• Soft key label - Determines the name to be displayed on the soft key
• Function - Determines the function to be connected to the soft key.
• Value - Determines a value (for example, phone number) to a function. The value is only needed for
some functions.
• Control question - Determines if a Proceed? dialogue shall appear when pressing a soft key.
5.45.2.5 Configure Idle display groups (sub group)
By default, the name of a system profile is displayed in the handset. It is only needed to configure an idle
display group if a system name is not to be displayed in the handset.
Select System Profiles → System Profiles Sub Groups → Idle display groups → Idle display group 1.
• Show name of system profile - Determines if the name of the system profile shall be displayed in the
handset idle screen.
• Name of group - Determines the name of the group
5.45.2.6 Create System Profile using Predefined Sub Group
To create a system profile, it must be connected to the predefined sub groups.
Select System Profiles → System Profile X.
• Soft keys group - Determines if a soft group shall be used.
• Alarm settings group - Determines if a alarm settings group shall be used.
• Presence group - Determines if a presence group shall be used.
• Idle display group - Determines if an idle display group shall be used.
• Sound and alerts group - Determines sound and alerts shall be used.
5.45.2.7 Activate and Deactivate System Profile
When a system profile is created, it can be activated on the handset using the WinPDM/Device Manager.
For example, the application could be triggered by a positioning beacon. However, this section describes
how to activate the system profile using WinPDM.
58
TD 93426EN / 28 January 2022 / Ver. C
