SECTION 2 INSTALLATION AND PREPARATION FOR USE
______________________________________________________________________
2-5
2.3 THE A-2000 BIS MONITORING SYSTEM - EQUIPMENT AND SUPPLIES
The A-2000 BIS Monitoring System consists of the following basic components:
• A-2000 BIS Monitor
• Digital Signal Converter (DSC)
• Patient Interface Cable (PIC)
• BIS Sensor
• Detachable Power Cord
A pole clamp is also included; however its use is optional. The exact model of DSC, PIC
and compatible sensors depends on the system configuration. Please consult section
2.2.4 for more detail. Contact Aspect or your local representative for information on
additional equipment and accessories.
Figure 3 The A-2000 BIS Monitoring System
BIS Monito
r
Sensors
Monitor
Interface
Cable
DSC
DSC Pi
g
tail
Patient Interface
Cable
(
PIC
)
