IDA8 Global-Net User Manual242
© 2017, ATEÏS, member of PAX ProAV Group
IDA8.
3.2.10.2 Side Panel
Microphone and Loudspeaker:
Use the internal speaker and microphone of PPM-IT5.
Phone Jack:
3.5mm headphone jack: To connect to a external headphone output.
3.5mm mic port (close to RJ9 connector): To connect to an external microphone input.
RJ9 Connector:
To connect to a RJ9 telephone handset.
3.2.10.3 LCD Menu
All the buttons displayed on the PPM-IT5 will be configured via Terracom web interface, and used for
displaying and operation only.
The PPM-IT5 supports multi-language, allowing to set the language shown on each button. The default
language is English.
Menu:
MAIN: Display the Device button, Events buttons and Function buttons.
DIAL: For typing the telephone numbers, SIP URI and so on.
MESSAGE: Display the messages list.
SETTING: Display the setting information.
