Product Features 291
© 2017, ATEÏS, member of PAX ProAV Group
3.2.12 URGP16I16O
The URGP 16I16O is an extension unit for the IDA8-System, LAPG2T and ECS. The URGP16I16O provides
those systems with 32 additional alarm inputs and outputs. Each input is monitored and can be
programmed to trigger a digital audio message into a specific zone or group of zones. The URGP is
linked to the System units through a RS232 /RS485 monitored serial link.
3.2.12.1 Front Panel
Evacuation LED:
Light up in red when the Evacuation input is active or blinks while boot. The following table lists the
states of the Evac LED:
One of the Evacuation inputs is active.
Blinks 5 times after powered on.
Fault LED:
Display fault status of system. The following table lists the states of the Fault LED:
To Next Page
