DSP Components 433
© 2017, ATEÏS, member of PAX ProAV Group
Element Description
Stop: Disable the action of audio streaming.
No.1- No.8: The channel of audio stream.
[...]: Click to open the window of channel setting.
Application
There are several types as the server of Ethernet audio stream: Terra Server, Terracom device or
computer software such as VLC Media Player. The picture below shows how to use the Audio Matrix
on Ateis Web Interface to set the preset of audio stream on TerraServer.
5.5 Feedback
The Feedback analyzes the signal, detects the feedback and attenuates the responsible frequency.
There is several types of feedback components. The difference is only the bandwidth which is tuned for
Music higher than speech(the bandwidth is decreasing between it). Each category has 4 kinds of
feedback filters(4, 8 12 or 16). The attenuation time of feedback is increased by the number of filters.
