Ateis IDA8 User Manual

IDA8 Global-Net User Manual552
© 2017, ATEÏS, member of PAX ProAV Group
Dimensions(L x W x H):
255mm x 108mm x 66mm
DialPad)
24 VDC@ 30 mA maximum
24 VDC@ 20 mA sleeping mode
Battery Holder:
4”AAA”
6 VDC@ 100mA maximum
6 VDC@ 70mA sleeping mode
Weight:
0.5kg
Colour:
RAL7016
Environmental
Operating temperature:
0ºC ~ 40ºC
7.4.3 Wireless Transceiver
Mechanical
Dimensions(L x W x H):
100mm x 67mm x 30mm
POWER LED:
Green
ø 3mm
Display for Power supply
STATUS LED:
Green
ø 3mm
Display the status of RF
RS485 Protocol:
RJ45 @Maximum Distance 500M{between system unit and
DialPad
24 VDC@ 30 mA maximum
RS232 connection:
DB9 @Maximum Distance 12M(between system unit and
DialPad Receiver
DC POWER connection:
DC-JACK@ 24V
24 VDC@ 30 mA maximum
Weight:
0.1 kg (0.2 lbs)
Colour:
RAL7016
Environmental
Operating temperature:
0ºC ~ 40ºC
7.4.4 DNM-485/DNM-ENET
Electrical & Connector
Power supply:
POE input:
EURO block input:
20VDC power supply (if no POE available)
Conform IEEE 802.3af
18~30 VDC, 250mA
Ethernet port:
CAT-5 cable
RS485 port:
5.08 mm EURO block(4Pin)
Include 24 VDC power:
18~30 VDC
Include RS485 of baud rate:
38400 bps @600M
Microphone:
Omnidirectional
Microphone
RS485 or Ethernet interface including POE (Power On Ethernet)
Built in Electronic Condenser microphone(omnidirectional)
Microphone input(1kHz):
-40 du
Maximum Cable Length:
600M on category 5 cable
